Can integrated and split chillers achieve the same cooling performance?

Yes. In most industrial applications, both integrated and split chiller systems can achieve similar cooling capacity, temperature stability, and process cooling performance when properly selected and configured.

Which system is more suitable for temporary projects?

For temporary projects, integrated chillers are usually more favored because their installation, commissioning, relocation and reconnection are all more convenient, which helps shorten the project cycle and reduce construction costs.

Which system is more affected by outdoor weather conditions?

Since some equipment is installed outdoors, the split system is more susceptible to weather conditions. Without taking appropriate protective measures, high temperatures, low temperatures, rain, snow, dust, and direct sunlight can all affect the operation of the equipment.

Is refrigerant charge different between integrated and split systems?

There are differences. The integrated chiller has completed the refrigerant filling process before leaving the factory. The overall filling volume will be preset according to the specifications of the unit. Generally, no additional filling is required during on-site installation. For the split chiller, since the indoor and outdoor units need to be connected with pipelines on-site, it usually requires additional filling of refrigerant after on-site installation based on the actual length of the pipeline. The total filling volume will be higher than that of the integrated water chiller with the same cooling capacity.

Can integrated chillers support multiple cooling zones?

Yes. With proper piping design, pump selection, and flow balancing, one integrated chiller can simultaneously serve multiple cooling zones, helping improve system efficiency and reduce overall equipment investment.
